The tesla comes with the flight case, a pair of Schaller Security Locks and an extended tool set. |
|
 |
 |
 |
guitar dimensions |
length: 770 mm (30.31 inches) width: 360 mm (14.17 inches) thickness: 55 mm (2.16 inches) |
||
case dimensions (inlcluding handles and wheels) |
length: 850 mm (33.46 inches) width: 415 mm (16.34 inches) thickness: 140 mm (5.51 inches) |
||
scale lenght |
648 mm (25.5 inches) |
||
body |
sides from American Alder (Red Alder) throughneck construction |
||
neck |
throughneck from Bird's Eye Maple asymmetrically V-shaped |
||
neck thickness |
20.0 mm (0.79 inches) at the 1st fret 22.8 mm (0.90 inches) at 16th fret |
||
neck width |
43.4 mm (1.71 inches) at the nut 56.0 mm (2.20 inches) at the 22nd fret |
||
fretboard radius |
350 mm (13,7") at the nut 450 mm (17,7") at the 22nd fret |
||
fretwire |
Jim Dunlop #6105 22 frets |
||
pickups |
1 humbucker hot PAF type AlNiCo8 1 or 2 splitcoils vintage |
||
guitar weight |
2,95 kg (6.5 lbs) |
||
string setup |
10"-46" Pyramid Nickel Plated |
||
|
 |
 |
 |
|
|
|
|
| copyright by Ulrich Teuffel |
